MODEL
|
|
KS-TE35
|
|
KS-TE45
|
|
FEATURE
|
LAYFLAT WIDTH
|
|
500 m/m
|
|
700 m/m
|
|
THICKNESS OF FILM
|
|
0.005~0.08 m/m
|
|
MAX. EXTRUSION OUTPUT
|
|
60 kg/hr
|
|
85 kg/hr
|
|
EXTRUDER
|
SCREW DIA.
|
|
35 m/m ø × 2
|
|
45 m/m ø × 2
|
|
SCREW L/D
|
|
30 : 1
|
|
30 : 1
|
|
SCREW CYLINDER MATERIAL
|
|
SACM 645 STEEL WITH HARD WITH NITROGEN TREATMENT
|
|
CYLINDER COOLING BLOWER
|
|
¼ HP × 4
|
|
¼ HP × 4
|
|
DRIVING MOTOR
|
|
10 HP × 2
|
|
20 HP × 2
|
|
HEATER CAPACITY
|
|
25 kw
|
|
30 kw
|
|
DIES
|
|
60 mm ø
|
|
85 mm ø
|
|
CONTROL PANEL
|
TEMPERATURE CONTROL
|
|
8 ZONES
|
|
10 ZONES
|
|
COOLING EQUIP
|
BLOWER
|
|
5 HP
|
|
5 HP
|
|
TAKE-UP UNIT
|
TYPE
|
|
FIXED TYPE
|
|
PINCH ROLLER (m/m)
|
|
165 ø × 550 L
|
|
165 ø × 750 L
|
|
TAKE-UP MOTOR
|
|
1 HP
|
|
1 HP
|
|
TAKE-UP SPEED (m/min)
|
|
12 ~ 120
|
|
12 ~ 120
|
|
SUB-PINCH ROLLER (m/m)
|
|
100 ø × 550 L
|
|
100 ø × 750 L
|
|
GUIDE MOTOR
|
|
15 kg/cm × 1
|
|
20 kg/cm × 1
|
|
WINDING UNIT
|
TYPE
|
|
ATTACHED TYPE, SURFACE, MANUAL TYPE
BOBBIN CHANGE
|
|
DIA. OF FILM WOUND-UP ROLL
|
|
800 mm
|
|
800 mm
|
|
EFFECTIVE WIDTH (m/m)
|
|
500
|
|
700
|
|
WINDER MOTOR
|
|
1 HP
|
|
1 HP
|
|
SHIPPING DATA
|
DIMENSION (L×W×H) (M)
|
|
4.0×2.3×4.0
|
|
5.0×2.5×4.5
|
|
OPTIONAL DEVICE
|
|
Gravimetric Dosing Unit
|
Oscillating Take Up Unit
|
|
IBC (Internal Bubble Cooing Computer Control System)
|
Line Speed Synchronized with Computer Control
|
|
Thickness Measurement
|
Two Stations Surface Winder
|
|
Thickness Controller
|
Chiller
|
|
Automatic Hopper Loader
|
Heat Slitting Device
|
|
Film Surface Treater
|
EPC (Edge Position Control)
|
|
Pressure Gauge
|
Electronic Tension Control
|
|
Rotary Die
|
Crane for Die and Air Shaft
|
Automatic Gauge Control with
Automatic Cooling Ring
|
PIB Pump System (For LDPE/LLDPE)
|
|
|
|
*Specifications are subject to change without notice for improvement.
